TECHNICAL SPECIFICATIONS

Dimensions: 206mm (W) × 143mm (H) × 153mm (D) *Housing body only.
Weight in air: 1.5 kg
Buoyance in water: negative 0.14kg (Incl. Ninja TX with NP-F970 battery)
Depth Rating: 100m
Vacuum valve: 25625 M16 Vacuum Valve II (pre-installed)
Compatible monitors: Ninja TX /TX GO/ RAW Monitor-Recorders
Compatible batteries: NP-F970 battery, SmallRig L-Series/NP-F970 USB-C
Rechargeable Camera Battery (10,500mah/76.65Wh capacity)

Ninja-TX monitor mounting compatible list

What’s in the box?
 NA-Atomos Ninja Tx Housing
 25625 M16 Vacuum Valve II (pre-installed)
 25089 M28 HDMI 2.0 Adaptor (pre-installed)
 17958 Mounting ball (pre-installed)
 Monitor hood
 90137 Housing O-ring, lubricant, O-ring remover
 CR2032 Battery (for moisture alarm and vacuum system)
 Allen Wrench Set
 Padded Travel Case
Main Features:
 Rotary Housing Lock
 Support HDMI in & SDI out (cross conversion), SDI in & SDI out
 Compatible with Sony NP-F series battery, and SmallRig L-Series/NP-F970 USB-C
Rechargeable battery, Max. size (Lx W x D): 71.6 x 38.5 x 74.6.
 Vacuum check and leak detection system
 Accessory ports on top: 2x M16, 2x M28
 Accessory ports on bottom: 1x M28
 Mounting thread holes on both top and bottom: 4x 1/4-20 for Housing Mounting
System (#17951), 4x M3 for mounting ball (#17958)
